Camera 3D PTZ Joystick Controller for EVI D70 VISCA Protocol PELCO P/D Protocol Keyboard from IGEECOO
About this item.
1. Support SONY VISCA, PELCO-D, PELCO-P, CISCO, POLYCOM, CANON, PANISONIC and other video conference cameras
2. Can control 64 video conference cameras, Each protocol and baud rate independent setting, support multiple brands controlling simultaneously
3. Support VISCA, CISCO, POLYCOM protocol, support preset position storing, 8 preset positions for each channel
4. The address of VISCA, CISCO protocol can be automatically assigned by the keyboard controller.
5. Use the high-end joystick, flexible manipulation, perfect feeling, high accuracy, just the same as SONY original
6. Backlight of the keys is adjustable with 10 grades
7. Support video switcher switch simultaneously, Communication converter switch simultaneously
8. Support central forwarding function, Support central Controller and the keyboard control the camera simultaneously
9. 1*RS232,1*RS485/422
|
Simple Introduction Parameter
|
|
|
Protocol
|
VISCA, PELCOP/D, Polycom, Cisco, Canon, Panisonic
|
|
Baud Rate
|
1200, 2400, 4800, 9600, 19200
|
|
Joystick
|
Three-Dimension+button, light coding, accuracy ±80 level
|
|
LCD Display Screen
|
English character version, blue backlight, 20 characters, 2lines
|
|
Button
|
28 keys, Double color backlight, 10 level of brightness
|
|
Control Cameras
|
64
|
|
Switching Matrix
|
Can control 1 video matrix with 8 inputs and 4 outputs
|
|
Communication Dispatcher
|
16X4=64, can control 16 communication dispatchers, each one divides into 4
|
|
Interface
|
|
|
Interface
|
1*RS485 interface, 2000 meters distance for camera controlling;
1*RS232 interface, Support communication dispatcher serial port expansion(max. 64) for camera controlling; 1*RJ45(RS485/RS232) for Video communication matrix; 1*USB connect to PC host for system controlling; |
|
Power Supply
|
DC12V/500mA
|
